· Mide corriente CA/CC hasta 600 A y voltaje CA/CC hasta 600 V
· Mide temperatura de -40 °C a 400 °C
· Mide salida de microamperios de CC para probar funcionamiento adecuado del sensor de llama en aparatos de gas
· Mide capacitancia, prueba diodos y cuenta con un pitido de continuidad
· Prueba la secuencia trifásica y la rotación del motor para garantizar la conexión adecuada de un motor a un sistema trifásico
· Supervisa la corriente de irrupción durante el arranque del motor
· Detección True-RMS para medición de voltaje precisa en entornos eléctricos ruidosos
· Función Amp-Tip permite mediciones de corriente CA baja: de 0 a 60 A
· Con filtro de paso bajo para medir voltaje y corriente en variadores de frecuencia
· Mide resistencia y continuidad para verificar calidad de las conexiones eléctricas y correcto funcionamiento de las bobinas del motor y el transformador.
· Proporciona retención de datos, cero relativo y modo MAX/MIN/AVG para rápido análisis
· Apagado automático e indicador de batería baja
· Pantalla retroiluminada: fácil visualización de la medición en entornos brillantes y oscuros
· Clasificación de seguridad CAT III 600 V
· Admite conductores de hasta 35 mm
|
AMP-310 |
AMP-320 |
AMP-330 |
|
AC Clamp Meter HVAC |
AC/DC Clamp Meter Electrical Motor Maintenance |
AC/DC 1000 A Clamp Meter Industrial Motor Maintenance
|
Safety Rating |
CAT III 600 V |
CAT III 600 V |
CAT IV 600 V, CAT III 1000 V
|
Jaw Opening |
1.18 in (30 mm) |
1.37 in (35 mm) |
2.0 in (51 mm)
|
AC Voltage (True-RMS) |
Range: 0 to 600.0 V Accuracy: ±1.0% + 5LSD (50 to 60 Hz) |
Range: 0 to 1000 V Accuracy: ±0.8% + 5LSD (50 to 60 Hz) ±1.5% + 5LSD (20 to 200 Hz) ±10% + 5LSD (200 to 400 Hz)
|
|
DC Voltage |
Range: 0 to 600.0 V Accuracy: ±1.0% + 5LSD |
Range: 0 to 1000 V Accuracy: ±0.8% + 5LSD
|
|
AC+DC Voltage |
– |
Range: 0 to 600.0 V Accuracy: 1.2% ± 7LSD (DC, 50 to 60 Hz) |
Range: 0 to 1000 V Accuracy: ±1.0% + 7LSD (50 to 60 Hz) ±1.8% + 7LSD (DC, 40 to 200 Hz) ±12% + 7LSD (200 to 400 Hz)
|
AC Current (True-RMS) |
Range: 0 to 600.0 A Accuracy: ±1.8% + 5LSD (50 to 100 Hz) ±2.0% + 5LSD (100 to 400 Hz) |
Range: 0 to 1000 A Accuracy: ±1.8% + 5LSD (40 to 100 Hz) ±2.2% + 5LSD (100 to 400 Hz)
|
|
DC Current |
– |
Range: 0 to 600.0 A Accuracy: ±2.0% + 5LSD |
Range: 0 to 1000 A Accuracy: ±1.8% + 5LSD
|
AC+DC Current |
– |
Range: 0 to 600.0 A Accuracy: ±2.2% + 7LSD (DC, 50 to 100 Hz) ±2.7% + 7LSD (100 to 400 Hz) |
Range: 0 to 1000 A Accuracy: ±2.2% + 7LSD (DC, 40 to 100 Hz) ±2.5% + 7LSD (100 to 400 Hz)
|
Precise Low Current AC |
Range: 0 to 60.00 A Accuracy: ±1.5% + 5LSD (50 to 60 Hz) |
Range: 0 to 60.00 A Accuracy: ±1.5% + 5LSD (0.00 to 20.00 A, 40 to 100 Hz) ±2.0% + 5LSD (0.00 to 20.00 A, 100 to 400 Hz) ±3.0% + 5LSD (20.00 to 60.00 A, 40 to 100 Hz) ±3.0% + 5LSD (20.00 to 60.00 A, 100 to 400 Hz)
|
|
Precise Low Current DC |
– |
Range: 0 to 60.00 A Accuracy: ±2.0% + 5LSD |
Range: 0 to 60.00 A Accuracy: ±1.5% + 5LSD (0.00 to 20.00 A) ±3.0% + 5LSD (20.00 to 60.00 A)
|
Precise Low Current AC+DC |
– |
Range: 0 to 60.00 A Accuracy: ±2.0% + 5LSD (DC, 50 to 60 Hz) |
Range: 0 to 60.00 A Accuracy: ±2.0% + 7LSD (0.00 to 20.00 A, DC, 40 to 100 Hz) ±2.2% + 7LSD (0.00 to 20.00 A, 100 to 400 Hz) ±3.0% + 7LSD (20.00 to 60.00 A, DC, 40 to 100 Hz) ±3.0% + 7LSD (20.00 to 60.00 A, 100 to 400 Hz)
|
Frequency |
Range: 5.00 to 999.9 Hz Accuracy: ±1.0% + 5LSD (600 V range) Range: 50.0 to 400.0 Hz Accuracy: ±1.0% + 5LSD (600 A range) |
Range: 5.00 to 999.9 Hz Accuracy: ±1.0% + 5LSD (1000 V range) Range: 40.0 to 400.0 Hz Accuracy: ±1.0% + 5LSD (1000 A range)
|
|
Resistance |
Range: 0.0 to 60.00 kW Accuracy: ±1.0% + 5LSD |
|
|
Capacitance |
Range: 0.0 to 2500 µF Accuracy: ±2.0% + 4LSD |
|
|
Continuity Beeper |
ON £ 10 W OFF > 250 W |
|
|
Non-Contact Voltage |
10V to 1000V AC, 50/60Hz |
|
|
True-RMS |
• |
• |
•
|
Low Pass Filter |
• |
• |
•
|
Autoranging |
• |
• |
•
|
Relative Zero |
• |
• |
•
|
MAX/MIN/AVG |
• |
• |
•
|
Diode Test |
• |
• |
•
|
Data Hold |
• |
• |
•
|
Backlight |
• |
• |
•
|
Auto Power Off |
• |
• |
•
|
300 Series: |
|
||
DC Microamps |
Range: 0.0 to 2000 µA Accuracy: ±1.0% + 5LSD |
|
|
Temperature* (Type K thermocouple) *Error does not include Type-K thermocouple errors |
Range: -40.0 to 752°F, -40.0 to 400°C Accuracy: -40.0 to 14.0°F (±1.0% +3.0°F), >14.0 to 99.9°F (±1.0% +1.5°F) 100 to 752°F (±1.0% +2°F), -40.0 to -10.0°C (±1.0% +1.5°C) >-10.0 to 99.9°C (±1.0% +0.8°C), 100 to 400°C (±1.0% + 1°C) |
|
|
3-Phase and Motor Rotation Indication |
Rotation-R for mains supply Rotation-M for motors |
|
|
Inrush Current |
• |
• |
•
|
Peak Hold (Crest) |
– |
– |
•
|
Work Light |
– |
– |
•
|
